Forming machinery
HP140 Sectional Flight Forming Machine
HP140 hydraulic pressing machine for sectional screw flights, with a catalogue maximum thickness of 18 mm and maximum OD of 500 mm.
Engineering fit
Built around the dimensions, material and production target that matter
The HP140 catalogue configuration uses a 30-ton hydraulic cylinder and a 4 kW motor.
Use the stated range as a practical starting point. We confirm the final configuration against your drawing, material and operating conditions.
Discuss this product
- Sectional screw flights
- Conveyor replacement segments
- Custom spiral blade forming
Product data
Product Specifications
| Parameter | Specification |
|---|---|
| Maximum thickness | 18 mm |
| Minimum ID | 32 mm |
| Maximum OD | 500 mm |
| Maximum pitch | 500 mm |
| Mould height | 260 mm |
| Machine size | 2,500 × 490 × 1,400 mm |
| Machine weight | 0.9 t |
| Motor power | 4 kW |
| Hydraulic cylinder | 30 t |
| Catalogue pressure | 20 MPa |
Workshop reference
Product and process views
Catalogue configuration
The HP Series catalogue lists HP140 with an 18 mm maximum thickness, 32 mm minimum ID, 500 mm maximum OD, 500 mm maximum pitch and 260 mm mould height. These separate limits require a combined drawing review.
Machine and site planning
The listed machine is 2,500 × 490 × 1,400 mm and weighs 0.9 t. Its listed motor is 4 kW and hydraulic cylinder is 30 t at 20 MPa. Confirm the electrical supply, tooling and installation requirements for the actual order.
Model selection
Compare the complete product range with HP100 and HP150 rather than selecting by maximum diameter alone.
Before quotation
Frequently asked questions
Use these answers as a starting point. Final geometry, material and equipment scope are confirmed from the project information.
What is the HP140 catalogue range?
The catalogue lists 18 mm maximum thickness, 32 mm minimum ID, 500 mm maximum OD and 500 mm maximum pitch. A complete drawing is still required for approval.
What should be checked before ordering tooling?
Review the blank, finished flight geometry, material grade and any special edge features against the proposed mould.
Continuous Screw Flight Cold Rolling Machine
A model-selection page for workshops planning continuous cold-rolled flight production across different strip widths, thicknesses and output targets.
View details
Continuous Screw Flight Winding Machine
Compare HW series mould-winding machines by strip thickness, pitch, outside diameter and maximum strip width.
View details
HP100 Sectional Flight Forming Machine
The HP100 catalogue configuration uses a 20-ton hydraulic cylinder and a 3 kW motor for sectional flight forming.
View details
HP150 Sectional Flight Forming Machine
The HP150 catalogue configuration lists a 700 mm maximum OD, 900 mm maximum pitch and 30-ton hydraulic cylinder.
View detailsEngineering review
Discuss your HP140 Sectional Flight Forming Machine requirement
Share the diameter, pitch, thickness, material, quantity and application. Our team will review the manufacturing route before quoting.
