HP150 Sectional Flight Forming Machine
HP150 hydraulic sectional flight forming machine with a catalogue maximum thickness of 18 mm and maximum OD of 700 mm.
Engineering fit
Built around the dimensions, material and production target that matter
The HP150 catalogue configuration lists a 700 mm maximum OD, 900 mm maximum pitch and 30-ton hydraulic cylinder.
Use the stated range as a practical starting point. We confirm the final configuration against your drawing, material and operating conditions.
Discuss this product
- Sectional conveyor flights
- Replacement blade segments
- Custom spiral blade forming
Product data
Product Specifications
| Parameter | Specification |
|---|---|
| Maximum thickness | 18 mm |
| Minimum ID | 20 mm |
| Maximum OD | 700 mm |
| Maximum pitch | 900 mm |
| Mould height | 360 mm |
| Machine size | 2,550 × 550 × 1,400 mm |
| Machine weight | 0.95 t |
| Motor power | 4 kW |
| Hydraulic cylinder | 30 t |
| Catalogue pressure | 20 MPa |
Workshop reference
Product and process views
Catalogue configuration
The HP Series catalogue lists HP150 with an 18 mm maximum thickness, 20 mm minimum ID, 700 mm maximum OD, 900 mm maximum pitch and 360 mm mould height. The limits are not an approval for every combined specification.
Machine and site planning
The listed size is 2,550 × 550 × 1,400 mm with a 0.95 t machine weight, 4 kW motor and 30 t hydraulic cylinder at 20 MPa. Final site utilities, mould scope and acceptance criteria belong in the approved quotation.
Model comparison
Compare target drawings with HP140 and HP180 when selecting tooling and machine scope.
Before quotation
Frequently asked questions
Use these answers as a starting point. Final geometry, material and equipment scope are confirmed from the project information.
What maximum OD does the HP150 catalogue specify?
The HP Series catalogue lists a 700 mm maximum OD for HP150. The target combination of geometry and material still requires drawing and tooling review.
Which drawings are needed?
Send the flat blank and finished segment drawings, including OD, ID, pitch, thickness, hand, material and any special features.
