Screw flight
Rounded-Edge Spiral Flight
Helical flight sections with a rounded edge profile, supplied from a confirmed section and finished-flight drawing.
Engineering fit
Built around the dimensions, material and production target that matter
A helical flight whose rounded edge is part of the specified section, requiring profile dimensions as well as the normal helix geometry.
Use the stated range as a practical starting point. We confirm the final configuration against your drawing, material and operating conditions.
Discuss this product
- Drawing-based replacement flights
- Profiled flight assemblies
- Equipment requiring a rounded flight edge
Product data
Product Specifications
| Parameter | Specification |
|---|---|
| Edge profile | Rounded section and orientation to be shown on the drawing |
| Helix geometry | Outside diameter, inside diameter, pitch, thickness and hand |
| Supply form | Individual sections or drawing-defined flight lengths |
| Material | Grade and supplied section to be confirmed before forming |
| Joining details | Shaft or tube fit and segment preparation stated by the buyer |
Workshop reference
Product and process views
Profile and helix must agree
A rounded-edge spiral flight is defined by two sets of geometry: the cross-section of the profiled strip or segment and the helix it must form. A standard OD, ID and pitch note does not fully describe the part.
Section information
Show the base width and thickness, rounded radius or profile, and which edge faces inward or outward after forming. If the section is supplied by the buyer, provide its material and dimensional tolerance. If it is to be sourced with the order, the available section must be reviewed before the flight is confirmed.
Finished-flight information
State outside diameter, inside diameter, pitch, hand, quantity and the required segment or assembly length. Include shaft or tube dimensions and any weld preparation when the flight will be assembled by the buyer.
When to choose this option
Use this product when the rounded edge is a functional drawing requirement rather than a general deburring request. For a flat-section single-pitch segment, select Sectional Spiral Blade. For a toothed outside edge, use Serrated Sectional Flight.
Quote checklist
- Section drawing with edge radius and orientation
- Material grade and supplied profile condition
- Flight OD, ID, pitch, thickness and hand
- Segment quantity or finished flight length
- Shaft or tube interface and joining method
- Critical edge and helix tolerances
- Existing sample and unworn profile reference
- Packing and identification requirements
Before quotation
Frequently asked questions
Use these answers as a starting point. Final geometry, material and equipment scope are confirmed from the project information.
Which edge of the flight is rounded?
The drawing must identify the rounded edge and its orientation after forming. Do not assume the inside and outside edges use the same profile.
What section dimensions are needed?
Provide the base thickness and width together with a dimensioned profile or a clear section drawing of the rounded edge.
Can the profile be copied from a worn sample?
A sample helps identify the shape, but wear can change the edge. A drawing or an unworn reference section is preferred for confirmation.
Is this a standard sectional flight?
It follows a helical form, but the profiled edge adds a separate forming and fit requirement. It should be quoted from both the section and helix drawings.
Square-Bar Flexible Auger
A flexible auger made from a square-section profile, with the bar section, coil geometry and installed tube route reviewed as one system.
View details
Cold-Rolled Continuous Screw Flight
Cold-formed strip flighting for applications that need continuous, seamless geometry and controlled pitch, diameter and thickness.
View details
Continuous Constant-Thickness Auger Flight
A continuous mould-winding route for multi-pitch flights where material utilization and consistent wall thickness are priorities.
View details
Sectional Spiral Blade
Single-pitch, equal-thickness helical segments for large diameter, thick plate, wear-resistant or stainless steel flight assemblies.
View detailsEngineering review
Discuss your Rounded-Edge Spiral Flight requirement
Share the diameter, pitch, thickness, material, quantity and application. Our team will review the manufacturing route before quoting.
